CPU | AnnapurnaLabs Alpine AL314 32-bit ARM® Cortex-A15 4-core 1.7GHz processor |
CPU Architecture | 32-bit ARM |
Floating Point Unit | Yes |
Encryption Engine | Yes |
System Memory | 2 GB SODIMM DDR3 (1 x 2 GB) |
Maximum Memory | 8 GB (1 x 8 GB) |
Memory Slot | 1 x SO-DIMM DDR3 |
Flash Memory | 512MB (Dual boot OS protection) |
Drive Bay | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot-swappable | Yes |
SSD Cache Acceleration Support | Yes |
Gigabit Ethernet Port (RJ45) | 2 |
10 Gigabit Ethernet Port | 1 x 10GbE SFP+ |
Wake on LAN (WOL) | Yes |
Jumbo Frame | Yes |
USB 3.2 Gen 1 port | 4 |
Form Factor | 1U Rackmount |
LED Indicators | HDD 1-4, Status, USB, LAN1-3 |
Buttons | Power, Reset |
Dimensions (HxWxD) | 44 × 439 × 291 mm |
Weight (Net) | 4.15 kg |
Weight (Gross) | 5.78 kg |
Operating temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | Open-frame 100W, Input: 100V-240V ~ / 3.5A, 50Hz-60Hz |
Power Consumption: HDD Sleep Mode | 12.42 W |
Power Consumption: Operating Mode, Typical | 30.99 W Tested with drives fully populated. |
Fan | System fan: 3 x 40mm, 12VDC |
System Warning | Buzzer |
Kensington Security Slot | Yes |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 400 |
