Drive Bay | 12 x 3.5-inch SATA 6Gb/s, 3Gb/s + 4 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Audio Alert On/Off Switch | Yes |
Form Factor | Tower |
Host Interface | 4 x SFF-8088 |
LED Indicators | HDD 1-16, Status, Link, Fan error |
LCD Display/ Button | |
Buttons | Power switch |
Dimensions (HxWxD) | 303.84 × 369.89 × 319.8 mm |
Weight (Net) | 11.59 kg |
Max. number of HDDs/SSDs supported | 16 |
Hard Drive Type | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives (for 3.5-inch tray slots only) 2.5-inch SATA solid state drives |
Operating temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | 250W PSU, 100 - 240V |
Power Consumption: Operating Mode, Typical | 93.66 W Tested with drives fully populated. |
Fan Mode Switch | (Auto, high, medium, low) |
Fan | 3 x 92mm, 12VDC |
System Warning | Buzzer |
Kensington Security Slot | Yes |
